PERISTALTIC PUMP TF-AMP22 pumps@techni-flow-pumps.com |
||||
| Range of peristaltic pumps | ||||
|
This range of péristaltics pumps TFAMP22 is the most powerful of péristaltics pumps TFAMP. It is able to generate flow of 1063l / hour which is very important for a péristaltic pump of this size. As standard the motorization is calculated to be able to use this péristaltique pump with a pressure of exit <4 bars, but this péristaltic pump is able to support a pressure of exit much upper < 8 bars, in that case it is advised to adapt the motorization as accordingly. - PERISTALTIC PUMP TFAMP10 - PERISTALTIC PUMP TFAMP13 - PERISTALTIC PUMP TFAMP16 - PERISTALTIC PUMP TFAMP19 |
 |
|||
| REFERENCE : Peristaltic fixed speed pump | FLOW /H ROTATION SPEED |
|||
| TFAMP22A10 |
250L/H
15TR/MN |
|||
| TFAMP22A11 |
339L/H
20TR/MN |
|||
| TFAMP22A12 |
428L/H
32TR/MN |
|||
| TFAMP22A13 |
561L/H
40TR/MN |
|||
| TFAMP22A14 |
664L/H
46TR/MN |
|||
| TFAMP22A15 |
797L/H
57TR/MN |
|||
| TFAMP22A16 |
974L/H
70TR/MN |
|||
| TFAMP22A17 |
1063L/H
85TR/MN |
|||
| REFERENCE : Peristaltic pump with mechanical speed variator | FLOW L/H ROTATION SPEED | |||
| TFAMP22A21 |
from 59 to 295l/h 4-20TR/MN |
|||
| TFAMP22A22 |
from 89 to 472l/h 6-32TR/MN |
|||
| TFAMP22A23 |
from 133 to 708l/h 9-48TR/MN |
|||
| TFAMP22A24 |
from 207 to 1048l/h 14-1048TR/MN |
|||
| Application case of peristaltics pumps TFAMP22: With this range of péristaltics pumps we really enter in the field of the transfer while the previous series were more used for applications getting closer to the dosage. The pumping of abrasive and corrosive viscous muds, in water-treatment plants. Pumping of enamel in the ceramic industry: the enamel is particularly difficult to pump with standard pumps because substances in suspensions in its composition are extremely abrasive, the péristaltic pump TFAMP22 with a low rotation speed is a low-cost solution of maintenance because the only wear part in touch with the fluid is the péristaltic flexible pipe which is easy to change by the operator and does not require a prolonged stop of the péristaltic pump.
|
